Brand Name : | ZONTOP |
Model Number : | ZOP2020 |
Supply Ability : | 2000 Unit/Units per Month |
Price : | $1,650.00/Units 15-49 Units |
Item | Specificdtions | ||||||
Dimension | L6000*W2440*H2920mm | ||||||
Top Frame | Main beam: 5580*3.0 --2pcs , 2140*3.0 --2pcs, Top corner part:210*150 --4pcs, Purlin: 80*40*1.2 Roof insulation cotton: 18m2 Colored steel sheet:0.4mm | ||||||
Bottom Frame | Main beam: 5580*3.0 --2pcs, 2140*3.0 --2pcs, Bottom corner part:210*150 --4pcs, Square tube100*50*1.8--14pcs | ||||||
Column | 3.0mm 210*150*2630 --4pcs | ||||||
Bottom frame accessory | 50S waterproof slot | ||||||
Floor | 18mm fiber cement board --5pcs 2.0mm PVC leather. 100mm glass wool insulation (16kg/m3) (optional) | ||||||
Wall panel | V950 50mm Rock wool sandwich panel (80kg/m3) 1150 75mm glass fiber sandwich panel (50kg/m3) 0.5mm steel sheet Fire rating: A | ||||||
Color | White (standard), other colors optional | ||||||
Roof | 1) Roof: 0.5mm colored-steel sheet (Color: Grey or optional) 2) Roof Insulation: 0.5mm colored steel sheet +100mm glass wool insulation, density 16KG/m³, Fire rating: A 3) Purlin: Section C80 Glvanized Steel. Thickness: 1.2mm | ||||||
Door | Steel door, High quality press lock Size: 970x2070mm Aluminium alloy door Size: 870x2070mm | ||||||
Window | Hollow plastic window with yarn fan and anti-theft net
Size:930x1200 2units | ||||||
Electricity System | 1) Double tube fluorescent light (usually 2 pcs) 2) The electrical lines inside the wall panels, copper core 2.5mm2 for lighting system. 4mm2 for AC units 3)16A socket -3pcs conditioning socket-1pcs 4) Electrical distribution box + breakers + earth leakage protective device | ||||||
Plumbing and Drainage | Pre-installed | ||||||
Downspout | 50PVC Downspout, 2750mm --4pcs | ||||||
Ceiling | Gypsum board 600x600mm or steel self connecting ceiling | ||||||
Ceiling seal | Aluminium seal Size 6000mm --3pcs | ||||||
Small parts | Drilling tail ,glue, connecting bolt (1set) |
![]() |
